駕駛室準乘人數(人)
|
3
|
外形尺寸
|
8080,8280,8380,8580,8880,9180,9480,10280,9980×2480,2550×3250,3420,3600
|
|
接近角/離去角(°)
|
17/22,17/18,17/15,17/14
|
前懸/后懸
|
1400/1980,1400/2280,1430/2150,1430/2450,1430/1950,1430/2250,1400/3080,1430/3050,1400/2780,1430/2750
|
|
備注
|
1、該車專用裝置:裝有靜音車廂,發電機組,電纜卷盤,控制系統等;用于應急搶險,并具備移動電源功能,廂體頂部封閉不可開啟;2、該車選用3800mm,4500mm,4700mm,5000mm,5300mm,5800mm軸距底盤改裝,整車外形長/前懸/軸距/后懸對應關系:7380/1400(1430)/3800/2180(2150),7680/1400(1430)/3800/2480(2450),8080/1400(1430)/4500/2180(2150),8380/1400(1430)/4500/2480(2450),8280/1400(1430)/4700/2180(2150),8580/1400(1430)/4700/2480(2450),8580/1400(1430)/5000/2180(2150),8880/1400(1430)/5000/2480(2450),9180/1400(1430)/5000/2780(2750),9480/1400(1430)/5000/3080(3050),8880/1400(1430)/5300/2180(2150),9180/1400(1430)/5300/2480(2450);9180/1400(1430)/5800/1980(1950),9480/1400(1430)/5800/2280(2250),10280/1400(1430)/5800/3080(3050),9980/1400(1430)/5800/2780(2750);3、防護材料:側后防護由車身結構代替,后防護下邊緣離地高:495mm;4、ABS型號/生產廠家:3631010-C2000/東科克諾爾商用車制動系統(十堰)有限公司,ABS 8/東科克諾爾商用車制動系統(十堰)有限公司, 4460046450/威伯科汽車控制系統(中國)有限公司,J ABS/焦作博瑞克控制技術有限公司;5.選裝上裝外觀,選裝液壓圍板,液壓升降尾板收起時水平距離為:300,尾板質量:440Kg,選裝不同內部裝置圖片用于應急搶險,選裝LED屏,嵌入式照明燈,卷簾門,對開門,帶玻璃對開門;后部選裝對開門,帶玻璃對開門,LED顯示屏,后部爬梯,選裝側門開啟樣式,選裝頂部升降照明燈,選裝后部外觀樣式.
|
|
軸距 (mm)
|
3800,3950,4200,4500,4700,5000,5300,5800,5600,5100
|
|
鋼板彈簧片數
|
7/9+6,8/10+8,8/9+6,11/10+8,3/10+8
|
前輪距
|
1876,1896,1920,1950,1914,1934,1980,2000,1815,1860
|
